HD2VCM-15

Dual Channel 12V 35 Amp Solid State Switch

The HD2VCM-15 has 2 inputs and 1 Output1 (One 70Amp 12V) where the Control Inputs are Voltage Level reponsive. IN1 and IN2 Control Output1. To Activate the Output of the HD2VCM-15, the must operate voltage is +5.5Von Vdc. The must release voltage is +2.5Voff Vdc. Note that the input voltage must drop to under +2.5Voff volts to turn it off.

Key Features:

  • Low Power Consumption: If the Control Voltage is not active (IN1 at GND) current draw is 0mA.
  • Control: Provides precise control for a +12V 70 Amp feed, allowing seamless switching of loads.
  • Versatility: Equipped with a microprocessor, enabling the controller to perform various functions based on customer-specified parameters.
  • Comprehensive Functionality Family Optional Configurations: Optionally offers voltage monitoring, current monitoring, low voltage disconnect, and efficient solid-state contactor control, providing a wide range of optional control options – Contact InPower.
  • Command Interface: User-friendly control interface via a 6 Pin Deutsch connector ensuring easy and secure connectivity.
  • Customizable Configuration: InPower’s expert team can assist customers in selecting the appropriate configuration ensuring the best fit for your requirements.

Specifications:

  • Low Power Consumption: If the Control Voltage is not active (IN1 at GND) current draw is 0mA.
  • Control: Provides precise control for a +12V 70 Amp feed, allowing seamless switching of loads.
  • Versatility: Equipped with a microprocessor, enabling the controller to perform various functions based on customer-specified parameters.
  • Comprehensive Functionality Family Optional Configurations: Optionally offers voltage monitoring, current monitoring, low voltage disconnect, and efficient solid-state contactor control, providing a wide range of optional control options – Contact InPower.
  • Command Interface: User-friendly control interface via a 6 Pin Deutsch connector ensuring easy and secure connectivity.
  • Customizable Configuration: InPower’s expert team can assist customers in selecting the appropriate configuration ensuring the best fit for your requirements.

Mechanical Drawings:

Diagram:
